Dome Mechanical FTTH Passive Optical Closure

Model: FTTH-08VM5
Place of Origin: Zhejiang,China (Mainland)
Dimension: 510x230(mm)
Max. Capacity: 96 fibers
Splitter Type: 2 pcs of 1x16 or 2x16 or 1 pcs of 1x32 or 2x32
Cable Type: outdoor cable, indoor cable or drop cable
No.of Port: multiple ports
Application: specially designed for FTTH application

inquiry

skype basketAdd to Basket  Edit

Share |

Product Description

Payment & Shipping Terms Supply Capacity
Trade Term:FOB,CIF,FCAPacking:4pcs/ctn,...
Payment Terms:T/TDelivery Date:in a week
Means of Transport:Ocean, Air, Land

Dome Mechanical FTTH Passive Optical Closure

FTTH passive optical closureFTTH passive optical closure




FTTH passive optical closureFTTH passive optical closure



FTTH passive optical closureFTTH passive optical closureFTTH passive optical closure


Description

> The FTTH-08VM5 from Optic Network Technology is specialized designed for FTTx application.

> The product is environmentally sealed enclosure for the fiber management system that provides the function of splice and passive component integration in the external network.


Features

Made from engineering plastic with high strength and anti-corrosion.

> Available 2 pcs of 1x16 or 2x16 or 1 pcs of 1x32 or 2x32 splitter.

> Suitable for wall-mounting or pole mounting application.

> 1 pcs of large round port for uncut cable and 4 pcs of small round port.

> Suitable for module type of PLC splitter with SC connector or LC connector, etc.

> Suitable for SC, or LC connect or customerized.

> Sealing method: mechanical sealing type.

> Dimension(HxD): 510x230mm


Application

> FTTH, FTTB, FTTC

> Telecommunication Network

> CATV

> Local Area Network


Dome Mechanical FTTH passive optical closure

Category: FTTH Optical Passive Splice Closure
