72 Fibers Or 144 Fibers Optical Enclosure

72 Fibers or 144 Fibers Optical Enclosure Admin Edit

Min. Order: 10 Piece/Pieces
Trade Term: FOB,CFR,CIF,FCA,EXW
Payment Terms: T/T
Place of Origin: Zhejiang, China (Mainland)
Means of Transport: Ocean, Air, Land
Packing: carton box
Delivery Date: in one week
Fiber Optic Splice Tray (FOST): Max. 3 pieces of FOST with 24 fibers per tray Max. Capacity (fibers): 72 fibers
Type of PLC: Tube type Type of Adapter: 17 pcs of SC duplex or quad LC
No. of Ports: 1 large round port and 4 small round ports Dimension (HxD)mm: 320x230

 FTTH-06VM5 I


                FTTH-06VM5 II


FTTH-06VM5


Description

The FTTH-06VM5 from is specialized designed for FTTx application.

The product adopts fully-mechanical sealing structure. It can be used for straight-through and branching-off application, as well as passive optical fiber distribution.


Features

· Made from engineering plastic with high strength and anti-corrosion.

· Suitable for wall-mounting or pole mounting application

· 1 pcs of large round port for uncut cable and 4 pcs of small round port

· Suitable for module type of PLC splitter with SC connector or LC connector, etc

· Suitable for SC, or LC connect or customerized

· Sealing method: mechanical sealing type

· Dimension  (HxD): 320x230mm


Application

· FTTH, FTTB, FTTC

· Telecommunication Network

· CATV

· Local Area Network


Ordering information

Model No.

FTTH-06VM5   I

FTTH-06VM5   II

Fiber   Optic Splice Tray

(FOST)

Max.   3 pieces of FOST with 24 fibers per tray

Max.   6 pieces of FOST with 24 fibers per tray

Max.   Capacity (fibers)

72   fibers

144   fibers

Type   of PLC

tube   type

/

6   pcs 1x8 OR 1x4 (tube type, without connector)

/

Type   of Adapter

17   pcs of SC duplex or quad LC

/

No.   of Ports

1   large round port and 4 small round ports

Dimension   (HxD)mm

320x230
